CHASSIS

  • Monocoque carbon - HP Composites
  • Bodywork carbon - HP Composites
  • Length: 4605mm
    width: 1900mm
    wheelbase: 2860mm
  • Weight: 950kg

SUSPENSIONS

  • Double wishbone
  • Pushrod and spring-damper combination
  • 4-ways through-rod Ohlins TTx40 dampers
  • Adjustable anti-roll bar system
  • 3º element front and rear

GEARBOX

  • 6-speed sequencial gearbox Xtrac 1152 with aluminium casing
  • Semi-automatic pneumatic steering wheel paddle-shift system - Megaline
  • Gearbox cooling with oil radiator

STEERING

  • Hydraulic power-assisted steering cooled by oil radiator

ENGINE* & ELECTRONICS

  • Nissan VK50+, V8 5.0 litros, 520cv
  • Gearbox and engine control units Magneti - Marelli

BRAKES

  • Brembo tracking package
  • 6-piston calipers front and rear 14" discs

*common for all the LM P3 manufacturers

RIMS

  • 18" magnesium 02 Racing - front width: 12,5" - rear width: 13"

SAFETY

  • 2020 ACO rules
  • Zylon side panels
  • Driver padding
  • New driver seat carbon shell
  • Double carbon seat homologated
  • Cockpit ventilation
  • Hans compatible headrest

Com o JS P320 as possibilidades são infinitas.

Detalhes do JS P320

Clique nos botões abaixo e saiba mais sobre cada detalhe:

Engine: Nissan VK50+ producing 520 horsepower

Fuel tank capacity: 100 litres

Race number background: Red

Tyres: Pirelli

Gearbox: 6 gears

Minimum weight: 950kg

Brakes: Steel discs 355.6mm with ABS
